Mud Mixing Systems

Goodeng GMS2000 Mud Mixing System Professional Compact Hydraulic Mixing Unit for HDD Drilling Rig Projects

Goodeng 2 cubic mud mixing system, with horizontal directional drilling rig, greatly improve the construction efficiency.
Our company has independently developed and produced a mud mixing system specifically designed for drilling and non excavation construction. After the product was developed and put into the market, it has received unanimous praise from multiple construction units. Mixing evenly, good effect, beautiful appearance, and convenient transportation.

Technical Parameter

Item	Metric Unit	Imperial Unit
Capacity	2000 L	528 gallon
Dimension	230013501500 mm	915359 inch
Weight	226 kg	498 lbs
Engine	3.6 KW	5hp
Cycling volume	25 m³/h	883 cf/h
Outlet	2 inch	2 inch
Lift	15 m	49 feet

Product Introduction

This product consists of a rapid mixing device, pump assembly, manifold, and tank body. According to different storage capacities, different mixing speeds can meet the needs of different customers.

1.The mud mixing system is suitable for the preparation and mixing of drilling fluid in trenching construction, drilling construction, non excavation construction, and horizontal directional construction.

2.It has the function of quickly preparing and mixing bentonite slurry.

3. The 3-cube mud mixing system is suitable for Goodeng Machine 20T 25T 32T 36T.

4. This prduct has superior performance and high efficiency.
